Green High-Tech Facility International Innovation Forum


Date: Friday, March 28, 2025
Time: 09:30-12:35
Venue: Grand Shanghai Ballroom 3, Kerry Hotel Pudong, Shanghai
Simultaneous Interpretation will be provided.

Attendee Registration   Previous Review

The report 《300mm Fab Outlook Report to 2027》released from SEMI points out，from 2025 to 2027, global spending on 300mm wafer fab equipment is expected to reach a record $400 billion, this is mainly benefit from the strong demand for artificial intelligence and related semiconductor components. In the course of this year, witnessed the wide application of silicon carbide (SiC) power devices in electric vehicles、innovative application of Chiplet technology in high-performance AI chip design、and the rapid rise of RISC-V architecture in automotive electronics and other fields. Besides, fourth generation semiconductor materials------ such as gallium oxide (Ga2O3) and aluminum nitride (AlN) are also beginning to emerge, shows great potential. According to SEMI's report, it will grow a further 24% by 2025, it exceeded $100 billion for the first time, achieve $123.2 billion. This growth is particularly significant, driven by the field of artificial intelligence, demand for Gpus and high bandwidth memory (HBM), further promote the prosperity of the semiconductor market.

Semiconductor production processes typically have high energy consumption、high water consumption、characteristics of high frequency production and discharge of toxic and harmful pollutants. It mainly includes cleanroom system、mechanical system、specialty gas and bulk gas、water treatment system、exhaust system、vacuum system、power supply& automation system、construction、EHS system control and energy saving. This forum provides a exchange experience for global semiconductor companies、explore a platform for strategy resolution. Hope that through the holding of this forum to strengthen the semiconductor industry chain upstream and downstream synergy development, addressing environmental pollution (waste water, waste gas, waste) during semiconductor production, to realize the green and sustainable operation of semiconductor companies, and jointly promote the green transformation and upgrading of the industry.
